PL310

Applications

•  Valve controls

•  Joysticks / Master switches

Features

• Small dimensions

• Synchro flange

• Sintered bronze bearing

• Design flexibility •  5 Mio. cycles

• Excellent linearity,  up to ±0.25%

• Very good resolution  better 0,1°

Options

•Resistance tolerance ±10%

• Independent linearity  ±0.25%

• Custom electrical angles and  switch functions available

• Mechanical end stops

• Protection class IP65

•  Custom shaft design

•  Custom housing design

• Ball bearings
